Geometric Dimensioning and Tolerancing is a system for defining and communicating engineering tolerances. It  uses a symbolic language on engineering drawings and computer-generated three-dimensional solid models  that explicitly describe nominal geometry and its allowable variation. It tells the manufacturing staff and machines what degree of accuracy and precision is needed on each  controlled feature of the part.

ISO defines GD&T as “geometrical product specifications (GPS)—Geometrical tolerancing—Tolerancing of form,  orientation, location and run-out.” In short, “geometrical product specifications” refer to the shape, size, and  positional relationship of a product, while “tolerance” means the allowable error. “Geometric tolerance” is  characterized by a definition that includes the allowable errors for the form and position in addition to size.

Applications

  • Provides a precise and consistent method for communicating design intent
  • Establishes a coordinate system (that references the datum features) for inspection and  manufacturing
  • Reduces the need to explain complex requirements
  • Facilitates and simplifies gaging requirements
  • Identifies critical-to-function features
  • Simplifies tolerance analysis

GD&T Course Highlights:

GD&T Foundation :

  • Introduction
  • Advantage of GD&T
  • Feature And Rules in GD&T
  • Datum Controls
  • Fundamental of Routing
  • Creating Routing Components
  • Using P & ID files
  • Tolerances in GD&T
  • Adding GD&T To a Drawing/design

Duration :

  • 25 Hours Theory
  • 25 Hours Practical
  • 20 Hours Project work

Technical Features:

Introduction

Geometric Dimensioning and Tolerancing is a system for defining and  communicating engineering tolerances. It uses a symbolic language on engineering drawings and  computer-generated three-dimensional solid models that explicitly describe nominal geometry  and its allowable variation.

advanced design training indore

Advantage

Why is geometric tolerance necessary?

For example, when the designer orders sheet parts, the size tolerance-based instructions will be as  follows:

These parts are non-conforming or defective products. These parts are produced because there is no mention of parallelism in the drawing. The fault lies with the tolerance instruction by the designer, and not with the manufacturer.

The drawing for the same part will be as follows using geometric tolerance. Here, the geometric characteristics  “parallelism” and “flatness” are used in addition to size. This can prevent errors like those we saw above with size  tolerance.

Geometric tolerance has the advantage of accurately and efficiently communicating the designer’s intended  design in a way that cannot be expressed using size tolerance alone

, GD&T Design Training Institute In India
, GD&T Design Training Institute In India

Feature and Rules

  •  Rule -1: Rule 1 states that where only a tolerance of size is specified, the limits of size of an individual feature of  size prescribe the extent to which variations in its geometric form, as well as its size, are allowed. No  element of a feature shall extend beyond the MMC boundary of perfect form. The form tolerance  increases as the actual size of the feature departs from MMC toward LMC. There is no perfect form  boundary requirement at LMC
  •  Rule -2: Rule 2 states that RFS automatically applies, in a feature control frame, to individual tolerances of size  features and to datum features of size. MMC and LMC must be specified when these conditions are  required.
, GD&T Design Training Institute In India
, GD&T Design Training Institute In India

Tolerances in GD&T

  •  Form Tolerances
  •  Orientation Tolerances
  •  Profile Tolerances
  •  Location Tolerances
  •  Run out Tolerances
, GD&T Design Training Institute In India

Adding GD&T To A Drawing/design

Step 1: Define Part features that would serve as origin with specific directions for  measurement

  • This step relates to Datums. Datums need to be selected based on the following criteria:
  • Representative of Mating Features
  • Reflect Functional Assembly
  • Stable
  • Repeatable
  • Accessible

Step 2: Specify Nominal (Basic) Dimensions for Location and/or Orientation of Features from  Datums

Step 3: Specify Tolerance Zone Boundaries for Part Features in terms of shape and size along  with specific rules for compliance

Step 4: Allow Dynamic Interaction of Tolerance Zones between Features in a Part, and across parts, simulating  Assembly possibilities for Maximizing Tolerances

Step 5: Cost of Precision Vs Cost of Poor Quality Analysis for Optimal Tolerances
